Adopt PLC digital temperature control in Chinese and English, intuitive and convenient operation, high-precision K-type temperature sensor, accurate temperature control. Progressive pre-heating melting tank design, first into the first melt, coated with Teflon anti-stick coating, energy consumption, reduce the phenomenon of plastic carbonization, can maintain the best quality of glue.
1.Using PLC temperature control system, LCD touch screen display, intuitive and convenient operation, accurate temperature control.
2.The PLC control system of this machine is also attached with glue spraying control program, without external glue spraying controller, with automatic speed and glue quantity tracking function, which can easily realize various glue spraying requirements of customers' products in the assembly line and automatic equipment.
3.The desian of progressive preheat melting tank,internal coating of imported DuPont Teflon anti sticking coating, low energy consumption reduce glue carbonization phenomenon, can maintain good glue quality.
4.Heat preservation and standby setting funcion can set the heat preservation temperature according to the actual production requirements, prevent glue carbonization, reduce power consumption, and shorten the heating time due to shift change or noon break.
5.When the actual temperature exceeds the set value, the main power supply will automatically turn off.
6.Timing switch function, namely 7-day time control function. The machine can be set to run and shut down automalicall according to theworking hours of workers every day.
7.The double-layer 100 mesh filter is adopted to reduce the clogging of the nozzle. The new guiding reflux device makes the glue pressure adjustment more accurate and stable.
8.The frame type self buckle shell design is beautiful and easy to repair and maintain.
9.High precision imported gear pump, stable output and high pressure.
10.The inverter protection function, when the actual temperature of the rubber tank does not reach the set temperature value, the motor does not work. plays a protective role, prolongs the service life of the equipment and avoids the economic losses caused by the illegal operation of employees.
Model | OSD-820B |
Voltage | 220V |
Frequency | 50/60HZ |
Power | 4500W |
Hopper Capacity | 20kg |
Melt Rate | 20kg/h |
MAX.CPS | 1,000-20,000CPS |
Rang of Temperature | <=250℃ |
Weight | 90kg |
Overall Size | 850mm*520mm*1060mm |
