OSD-800mm Hot Melt Roller Machine

Feature

1. This style gluing machine is specially tailored for EPE pearl cotton deep processing factory.

2. The appearance is simple and beautiful, the design is reasonable, easy to disassemble, with adjustable height gauge, the height of the rollercan be adjusted from 5mm-200mm.

3. The main rotaion system adopts stepless speed control, roler,glue tank independent temperalure control, dual temperature protection plasticbucket with Teflon coating to greatly reduce the oxidation of the glue to ensure reliable product quality.

4. The gluing roler can be customized according to the user's needs, such as flat, textured, dot, groove and other shapes.

5. The use of joint venture brand motor and imported electronic components, free warranty for the next year.

6. All precision hardware components are manufactured by imported CNC machining centers and are guaranteed for the following year.

Technical Parameters

Model	OSD-800MM
Voltage	220V
Frequency	50/60HZ
Power	4500W
Thnk capacity	10kg
Max Melt Rate	10kg/h
MAX.CPS	20,000CPS
Rang of Temperature	<=250℃
Weight	120kg
Overall Size	1100mm470mm550mm
